DJI Mini 5 Pro Fly More Combo - DJI RC-N3

0 reviews

$959.00

The DJI Mini 5 Pro features a 1-inch CMOS camera, nightscape omnidirectional obstacle sensing, a gimbal with 225° of flexible rotation, and upgraded ActiveTrack 360°, all packed into its signature lightweight body.

About this Product

The DJI Mini 5 Pro features a 1-inch CMOS camera, nightscape omnidirectional obstacle sensing, a gimbal with 225° of flexible rotation, and upgraded ActiveTrack 360°, all packed into its signature lightweight body. With performance on par with flagship drones, it captures life’s beautiful moments and preserves your treasured memories in stunning detail.

VIDEO: Meet DJI Mini 5 Pro - All-In-One 1-Inch Large CMOS Mini Camera Drone

Features

1-Inch CMOS Sensor, Capture Like a Pro
Nightscape Omnidirectional Obstacle Sensing
True Vertical Shooting and 225° Flexible Gimbal Rotation
Extended Battery Life, Up to 36 minutes of flight time
Upgraded ActiveTrack 360°
Lightweight and Portable

Specifications

AIRCRAFT

Takeoff Weight: Approx. 249.9 g
Dimensions:
- Folded (without propellers): 157×95×68 mm (L×W×H)
- Unfolded (with propellers): 304×380×91 mm (L×W×H)
Max Ascent Speed:
- 3 m/s (C mode)
- 6 m/s (N mode)
- 10 m/s (S mode)
Max Descent Speed:
- 3 m/s (C mode)
- 6 m/s (N mode)
- 6 m/s (S mode)
Max Horizontal Speed:
- 15 m/s (tracking status)
- 18 m/s (S mode)
Max Takeoff Altitude: 4500 m
Max Flight Time: Approx. 36 mins
Typical Flight Time: Approx. 21 mins
Max Flight Distance: 21 km
Max Wind Speed Resistance: 12 m/s
Operating Temperature: -10° to 40°C (14° to 104°F)
Global Navigation Satellite System: GPS + Galileo + BeiDou
Internal Storage: 42 GB
Class: C0 (EU)

CAMERA

Image Sensor: 1-Inch CMOS, 50MP Effective Pixels
Lens:
FOV: 84°
Format Equivalent: 24 mm
Aperture: f/1.8
Focus: 0.5 m to ∞
ISO Range:
- Video
  Normal:
  100-12800 (Normal)
  100-3200 (D-Log M)
  100-3200 (HLG)
  Slow Motion:
  100-6400 (Normal)
  100-3200 (D-Log M)
  100-3200 (HLG)
- Photo
  100-6400 (12 MP)
  100-3200 (50 MP)
Shutter Speed:
- 12MP Photo: 1/8000-2 s (2.5-8 s for simulated long exposure)
- 50MP Photo: 1/8000-2 s
Max Image Size: 8192×6144
Photo Format: JPEG/DNG (RAW)
Video Resolution:
- H.264/H.265
- 4K: 3840×2160@24/25/30/48/50/60/120*fps
- FHD: 1920×1080@24/25/30/48/50/60/120*/240*fps
  * Recording frame rates. The corresponding video plays as a slow-motion video. Slow-motion videos and 4K video recordings only support H.265 encoding
Video Format: MP4 (MPEG-4 AVC/H.264, HEVC/H.265)
Max Video Bitrate: H.264/H.265: 130 Mbps
Color Mode:
- Normal (FHD):
  8-bit 4:2:0 (H.264)
- Normal (FHD/4K):
  10-bit 4:2:0 (H.265)
- HLG/D-Log M:
  10-bit 4:2:0 (H.265)
Camera FOV
Single Lens Mode:
With RC 2/RC-N2/RC-N3: Natural Wide
With Goggles 3/N3 paired with RC Motion 3 or FPV Remote Controller 3: Standard (Dewarp)/Wide/Natural Wide
Digital Zoom:
- 12MP Photo: 1-3x
- 4K: 1-3x
- FHD: 1-4x
Supported File System: exFAT

GIMBAL

Stabilization: 3-axis mechanical gimbal (tilt, roll, pan)
Mechanical Range:
- Tilt: -135° to 80°
- Roll: -230° to 95°
- Pan: -25° to 25°
Controllable Range
- Tilt: -90° to 55°
- Roll: -180° to 45°
Max Control Speed: 100°/s
Angular Vibration Range: ±0.005°

VIDEO TRANSMISSION

Video Transmission System: O4+
Live View Quality: Remote Controller: 1080p/30fps, 1080p/60fps
Operating Frequency:
- 2.400-2.4835 GHz
- 5.170-5.250 GHz*
- 5.725-5.850 GHz
  Operating frequency allowed varies among countries and regions. Refer to local laws and regulations for more information.
Transmitter Power (EIRP):
- 2.400-2.4835 GHz:
  < 33 dBm (FCC)
  < 20 dBm (CE/SRRC/MIC)
- 5.170-5.250 GHz:
  < 23 dBm (CE)
- 5.725-5.850 GHz:
  < 33 dBm (FCC)
  < 30 dBm (SRRC)
  < 14 dBm (CE)
Max Transmission Distance (unobstructed, free of interference):
FCC: 20 km
CE: 10 km
SRRC: 10 km
MIC: 10 km
Max Transmission Distance (unobstructed, with interference):
Strong Interference: Urban landscape, approx. 1.5-4 km
Medium Interference: Suburban landscape, approx. 4-10 km
Low Interference: Suburb/seaside, approx. 10-20 km
Max Transmission Distance (obstructed, with interference):
Low Interference and Obstructed by Buildings: Approx. 0-0.7 km
Low Interference and Obstructed by Trees: Approx. 0.7-4.5 km
Max Download Speed:
O4+: 10 MB/s
Wi-Fi 6: 100 MB/s*
* Measured in a laboratory environment with little interference in countries/regions that support both 2.4 GHz and 5.8 GHz, and when internal storage or a high-speed microSD card is used. Download speeds may vary depending on the actual conditions.
Lowest Latency: Aircraft + Remote Controller: Approx. 120 ms
Antennas: 4 antennas, 2T4R

INTELLIGENT FLIGHT BATTERY

Capacity: 2788 mAh
Weight: Approx. 71.2 g
Nominal Voltage: 7 V
Max Charging Voltage: 8.6 V
Battery Type: Li-ion
Energy: ≥ 19.52 Wh
Charging Temperature: 5° to 40° C (41° to 104° F)
Charging Time:
- 1 battery can be fully charged in approx. 69 minutes by charging through the drone using the DJI 65W Portable Charger.
- 1 battery can be fully charged in approx. 46 minutes using the Two-Way Charging Hub and DJI 65W Portable Charger.
- 3 batteries can be fully charged in approx. 115 minutes using the Two-Way Charging Hub and DJI 65W Portable Charger.

BATTERY CHARGING HUB

Input: 5-15 V, max 4.3 A
Output: 5-15 V, max 2 A
Compatibility: DJI Mini 5 Pro Intelligent Flight Battery, DJI Mini 5 Pro Intelligent Flight Battery Plus

WI-FI

Protocol: 802.11 a/b/g/n/ac/ax
Operating Frequency: 2.400-2.4835 GHz, 5.725-5.850 GHz
Transmitter Power (EIRP):
- 2.400-2.4835 GHz:
  < 20 dBm (FCC/CE/SRRC/MIC)
- 5.725-5.850 GHz:
  < 26 dBm (FCC/SRRC)
  < 14 dBm (CE)

BLUETOOTH

Protocol: Bluetooth 5.4
Operating Frequency: 2.400-2.4835 GHz
Transmitter Power (EIRP): < 10 dBm

DJI RC-N3 REMOTE CONTROLLER

Max Operating Time:
- Without charging any mobile device: 3.5 hours
- When charging a mobile device: 1.5 hours
Operating Temperature: -10° to 40°C (14° to 104°F)
Charging Temperature: 5° to 40°C (41° to 104°F)
Charging Time: 2 hours
Charging Type: It is recommended to use a 5V/2A charger.
Battery Capacity: 9.36Wh (3.6V,2600 mAh)
Weight: Approx. 320 g
Dimensions: 104.2×150×45.2 mm (L×W×H)
Supported Mobile Device Port Type: Lightning, USB-C, Micro-USB
Using a mobile device with a Micro-USB port requires the DJI RC-N Series RC Cable (Standard Micro USB Connector), which is sold separately.
Operating Frequency:
- 2.400 GHz to 2.4835 GHz
- 5.170 GHz to 5.250 GHz
- 5.725 GHz to 5.850 GHz
Transmitter Power (EIRP):
- 2.4 GHz: < 33 dBm (FCC), < 20 dBm (CE/SRRC/MIC)
- 5.1 GHz: < 23 dBm (CE)
- 5.8 GHz: < 33 dBm (FCC), < 14 dBm (CE), < 30 dBm (SRRC)
